Ex Proof Wire Rope Hoist Technology
The largely maintenance-free components of the modular wire rope hoist are optimally matched to each other. They guarantee constant performance, high efficiency and long service life. The standard safety components such as gear limit switch, motor temperature control and overload device, or even an optional additional brake, increase workplace safety.
ES Series Hoist Models Comparison
| Model | Capacity | Modular design | Serially produced | Low headroom | Standard Headroom |
Monorail | Double Rail | Fixed /Foot mounted |
ES20
|
up to 3.2t |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
| ES30
|
up to 5t |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
| ES40
|
up to 6.3t |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
| ES50
|
up to 12.5t |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
| ES60
|
up to 20t |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
| ES70
|
up to 80t |
✔ |
Custom Build |
✘ |
✘ |
✘ |
✔ |
✔ |
| ES80
|
up to 160t |
✔ |
Custom Build |
✘ |
✘ |
✘ |
✔ |
✔ |
Modular Designed ES Series
Hoist Model |
Capacity |
|||||
 |
ES20 |
Up to 3,200 kg | ||||
| Reeving | Load Capacity (t) | HOL (m) | ||||
| 4/1 | 3.2 | 6 | 10 | 15 | ||
| 4/2 | 1.6 | 6 | 10 | 15 | ||
| 2/1 | 1.6 | 12 | 20 | 30 | ||
Hoist Model |
Capacity |
|||||
|
ES30 |
Up to 5000 kg | ||||
| Reeving | Load Capacity (t) | HOL (m) | ||||
| 4/1 | 5 | 6 | 10 | 15 | ||
| 4/2 | 2.5 | 6 | 10 | 15 | ||
| 2/1 | 2.5 | 12 | 20 | 30 | ||
Hoist Model |
Capacity |
|||||
|
ES40 |
Up to 6,300 kg | ||||
| Reeving | Load Capacity (t) | HOL (m) | ||||
| 4/1 | 6.3 | 6 | 10 | 15 | ||
| 4/2 | 3.2 | 6 | 10 | 15 | ||
| 2/1 | 3.2 | 12 | 20 | 30 | ||
Hoist Model |
Capacity |
|||||
|
ES50 |
Up to 12,500 kg | ||||
| Reeving | Load Capacity (t) | HOL (m) | ||||
| 4/1 | 12.5 | 6 | 10 | 15 | ||
| 4/1 | 10 | 6 | 10 | 15 | ||
| 4/2 | 6.3 | 6 | 10 | 15 | ||
| 4/2 | 5 | 6 | 10 | 15 | ||
| 2/1 | 6.3 | 12 | 20 | 30 | ||
| 2/1 | 5 | 12 | 20 | 30 | ||
Hoist Model |
Capacity |
|||||
|
ES60 |
Up to 20,000 kg | ||||
| Reeving | Load Capacity (t) | HOL (m) | ||||
| 4/1 | 20 | 6 | 10 | 15 | ||
| 4/1 | 16 | 6 | 10 | 15 | ||
| 4/2 | 10 | 6 | 10 | 15 | ||
| 4/2 | 8 | 6 | 10 | 15 | ||
| 2/1 | 10 | 12 | 20 | 30 | ||
| 2/1 | 8 | 12 | 20 | 30 | ||
Hoist Model |
Capacity |
|||||
|
ES70 |
Up to 80,000 kg | ||||
| Reeving | Load Capacity (t) | HOL (m) | ||||
Customised |
||||||
Hoist Model |
Capacity |
|||||
|
ES80 |
Up to 125,000 kg | ||||
| Reeving | Load Capacity (t) | HOL (m) | ||||
Customised |
||||||
JSC Yamal
Okan PRP Platform Project, Nigeria offshore
Wheatstone LNG Tank Jib Cranes
JCS Yamal LNG
Ichthys FPSO Daewoo
Test Rig for Ex EDL Cranes
