ES60 Hoist

Hoist ES60 Technical Data
Explosion proof hoist ES60 technical Data

Download Technical Data for ES60

Hoist ES60

Capacity Up to 20,000 kg
Model Load Capacity (t) Reeving HOL (m) FEM ISO Hoist Speeds (m/min) Trolley Speed (m/min)
ES 6016 3.2 2/1 12 20 30 4m M7     12/2 16/2.4 20/5 10/2.5
ES 6020 4.0 2/1 6 10 15 3m M6       16/2.4 20/5 10/2.5
ES 6020 4.0 4/2 12 20 30 4m M7 8/1.3 10/1.6 12/2   20/5 10/2.5
ES 6025 5.0 2/1 12 20 30 2m M5     12/2   20/5 10/2.5
ES 6025 5.0 2/1 12 20 30 1Am M4       16/2.4 20/5 10/2.5
ES 6025 5.0 4/2 12 20 30 4m M7 8/1.3       20/5 10/2.5
ES 6025 5.0 4/2 12 20 30 3m M6   10/1.6     20/5 10/2.5
ES 6032 6.3 2/1 12 20 30 3m M6 8/1.3       20/5 10/2.5
ES 6016 6.3 4/1 6 10 15 4m M7     6.3/1 8/1.3 20/5 10/2.5
ES 6032 6.3 4/2 12 20 30 2m M5   10/1.6     20/5 10/2.5
ES 6032 8.0 2/1 12 20 30 2m M5   10/1.6     20/5 10/2.5
ES 6020 8.0 4/1 6 10 15 4m M7 4/0.7 5/0.8 6.3/1   20/5 10/2.5
ES 6020 8.0 4/1 12 20 30 3m M6       8/1.3 20/5 10/2.5
ES 6032 8.0 4/2 12 20 30 2m M5 8/1.3       20/5 10/2.5
ES 6050 10.0 2/1 12 20 30 1Am M4   10/1.6     20/5 10/2.5
ES 6025 10.0 4/1 6 10 15 4m M7 4/0.7       20/5 10/2.5
ES 6025 10.0 4/1 6 10 15 3m M6   5/0.8     20/5 10/2.5
ES 6025 10.0 4/1 6 10 15 2m M5     6.3/1   20/5 10/2.5
ES 6025 10.0 4/1 6 10 15 1Am M4       8/1.3 20/5 10/2.5
ES 6050 10.0 4/2 12 20 30 1Am M4 8/1.3       20/5 10/2.5
ES 6032 12.5 4/1 6 10 15 2m M5   5/0.8     20/5 10/2.5
ES 6032 12.5 4/1 6 10 15 3m M6 4/0.7       20/5 10/2.5
ES 6032 16.0 4/1 6 10 15 2m M5 4/0.7 5/0.8     20/5 10/2.5
ES 6050 20.0 4/1 6 10 15 1Am M4 4/0.7 5/0.8     20/5 10/2.5
